8BVI0 Series ACOPOSmulti / ACOPOSmulti3 Inverter Modules — High-Performance Power Output for Multi-Axis Servo Systems

Subtitle:
Available from 1.9A to 200A with Single-Axis and Dual-Axis Configurations, Wall-Mount and Cold-Plate Mounting Options — A Scalable Power Platform for High-Dynamic Motion Control Applications.

Series Overview:
The 8BVI0 series is B&R's inverter module line for the ACOPOSmulti multi-axis servo drive system. These modules mount on the ACOPOSmulti mounting plate (8B0M0 series), converting DC bus voltage into controlled three-phase AC power to drive servo motors. The series offers current ratings from 1.9A to 200A, with single-axis and dual-axis configurations, as well as wall-mount (HW) and cold-plate/feed-through (HC) mounting options. The latest generation ACOPOSmulti3 models (suffix -3) are optimized for decentralized, computationally intensive control applications.


Contact Us

Why Choose Us

———

Profession

The company has a complete product line, including providing a wide range of industrial automation brand accessories

Experience

12 years of sales and distribution experience

Services

Focused on supplying products from world-renowned brands

Technical Support

We sell spare parts with one year warranty, which are rigorously tested and certified.

Key Features & Benefits:

FeatureBenefit
Complete Power RangeFrom 1.9A to 200A, covering applications from small machines to large production lines
Single / Dual-Axis FlexibilityModels ≤22A available in single or dual-axis configurations to optimize cabinet space
Multiple Mounting OptionsHW (wall-mount) and HC (cold-plate/feed-through) variants for different cooling requirements
Integrated Safety & ProtectionUncontrolled standstill and safe stop functions; short-circuit and ground fault protection
Intelligent IGBT Temperature ManagementBuilt-in mathematical IGBT model ensures reliable operation at maximum output; safe braking on temperature limit exceedance
Rich Expansion InterfacesMotor holding brake and temperature sensor connections; 2 slots for encoder interface modules (8BAC series)

Key Models Overview (Single-Axis, Wall-Mount):

ModelRated CurrentAxesMountingGeneration
8BVI0014HWS0.000-11.9 ASingleWall-mountACOPOSmulti
8BVI0014HWS0.000-31.9 ASingleWall-mountACOPOSmulti3
8BVI0028HWS0.000-13.8 ASingleWall-mountACOPOSmulti
8BVI0055HWS0.000-17.6 ASingleWall-mountACOPOSmulti
8BVI0110HWS0.000-115.1 ASingleWall-mountACOPOSmulti
8BVI0220HWS0.000-122 ASingleWall-mountACOPOSmulti
8BVI0440HWS0.000-144 ASingleWall-mountACOPOSmulti
8BVI0880HWS0.008-188 ASingleWall-mountACOPOSmulti
8BVI1650HWS0.004-1165 ASingleWall-mountACOPOSmulti
8BVI2000HWS0.000-1200 ASingleWall-mountACOPOSmulti

Source: B&R official product listing. Suffix -3 denotes ACOPOSmulti3 platform.

Key Models Overview (Dual-Axis, Wall-Mount):

ModelCurrent per AxisAxesMountingGeneration
8BVI0014HWD0.000-11.9 ADualWall-mountACOPOSmulti
8BVI0028HWD0.000-13.8 ADualWall-mountACOPOSmulti
8BVI0055HWD0.000-17.6 ADualWall-mountACOPOSmulti
8BVI0110HWD0.000-115.1 ADualWall-mountACOPOSmulti
8BVI0220HWD0.000-122 ADualWall-mountACOPOSmulti

Dual-axis modules are only available for current ratings ≤22A, saving cabinet space compared to single-axis modules.

Technical Specifications (Example: 8BVI0028HCD0.000-1):

ParameterSpecification
Model8BVI0028HCD0.000-1
Rated Current3.8 Aeff
Peak Current9.5 Aeff
Continuous Power2.87 kW
AxesDual
MountingHC (Cold-plate/feed-through)
Slot Count2 (for 8BAC encoder interface modules)
DC Bus Voltage750 VDC (nominal)
Switching Frequency5 / 10 / 20 kHz configurable
Protection RatingIP20
Operating Temperature5 to 40°C (nominal), 55°C (max.)
CertificationsCE, UKCA, cULus E225616, KC

Typical Applications:

  • Packaging & Printing — 8BVI0055 or 8BVI0110 driving multiple synchronized axes for high-speed registration control.

  • CNC Machine Tools — 8BVI0220 and above for spindle and feed axes requiring high torque and dynamic response.

  • Robotics — 8BVI0440 or 8BVI0880 driving multi-axis joints for complex trajectory motion.

  • Semiconductor Equipment — 8BVI0014 or 8BVI0028 driving precision linear motors for micron-level positioning.

Compatibility & Accessories:

Accessory TypeRelated Models / Notes
Mounting Plate8B0M0 series (provides slots and backplane bus)
Encoder Interface Modules8BAC series (EnDat / HIPERFACE / Resolver / SinCos)
Power Supply Modules8B0P0 / 8BVP series (DC bus supply)
Terminal Blocks8BZVI series (select according to model)
Fan Module8BXF001.0000-00 (optional cooling)
